Name: 500g Weight Sorting Machine
Brand: GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD
SKU: TY-A-CW-YP
Price: 18,500.00 USD
Availability: InStock

Home > products > Weight Sorting Machine >

500g Weight Sorting Machine

300 times/min Weight Sorting Machine

500g Weight Sorting Machine

500g automated sorting system

Place of Origin:

Guangdong zhongshan China

Brand Name:

TOUPACK

Certification:

Model Number:

TY-A-CW-YP

Request A Quote

Product Details

Max Weight:

500g

Sorting Accuracy:

0.5g

Control System:

MCU/PLC

Material:

Stainless Steel 304

Power Supply:

220/110V

Sorting Speed:

300 Times/min

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

Negotiable

Packaging Details

wooden case

Delivery Time

15-30 days after payment

Payment Terms

L/C, T/T

Supply Ability

50 Sets/month

PLC Automatic Weight Sorting Machine Chicken Whole Meat Grading Machine

Get Best Price

video

SUS 316 Weight Sorting Machine For Seafood Fish Fruits Vegetables

Get Best Price

video

Smart Auto Conveyor Check Weigher Machine For Red Shrimp Sausages Sorter Belt Weigher Weight Checker

Get Best Price

video

Multi Function Individual Vibration Feeder Incline Conveyor Capacity 7 Tons In Hour

Get Best Price

Contact Now

Product Description

500g Weight Sorting Machine

Product Specifications

Attribute	Value
Max Weight	500g
Sorting Accuracy	0.5g
Control System	MCU/PLC
Material	Stainless Steel 304
Power Supply	220/110V
Sorting Speed	300 times/min

Product Description

Horizontal Multi-Weight Sorting Conveyor Weighing For Raw Fish Lobster

Application

This fruit sorting machine is primarily designed for sorting and grading round-shaped fruits and vegetables including apples, pears, dragon fruit, oranges, peaches, kiwi fruit, and guava. The machine sorts products based on weight.

Main Features

Collect data automatically with accuracy - Data are collected in one pass without operator's intervention, ensuring its accuracy
Exception alarm - The equipment will alarm when packages' weight and dimension are beyond limit or the code cannot be read
Highly flexible with expandability - Can be equipped with cameras of different resolutions and connected to telescopic conveyors and conveyor belts

Technical Specifications

Model	TY-CW-YP
Power Supply	AC220V±10% 50HZ(60HZ)
Rated Power	0.6KW
Checking Range	≤500g
Accuracy	±0.3g~±3g
Minimum Scale	0.1g
Optimal Throughput	300 pcs/min
Suitable Product Dimension	≤120mm L*80mm W
Magazine Size	173mm*91mm
Rejector	Drop
Control Module	High Speed A/D Sampling Module
Product Preset	99
Conveyor Direction	Rotary
Operating Requirement	Temperature: 0℃~40℃, Humidity: 30%~95%
Machine Body Construction	SUS304 Full Stainless Steel
