Name: 500g Weight Sorting Machine
Brand: GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD
SKU: TY-A-CW-YP
Price: 18,500.00 USD
Availability: InStock

Home > products > Weight Sorting Machine >

500g Weight Sorting Machine

300 times/min Weight Sorting Machine

500g Weight Sorting Machine

500g automated sorting system

Place of Origin:

Guangdong zhongshan China

Brand Name:

TOUPACK

Certification:

Model Number:

TY-A-CW-YP

Request A Quote

Product Details

Max Weight:

500g

Sorting Accuracy:

0.5g

Control System:

MCU/PLC

Material:

Stainless Steel 304

Power Supply:

220/110V

Sorting Speed:

300 Times/min

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

Negotiable

Packaging Details

wooden case

Delivery Time

15-30 days after payment

Payment Terms

L/C, T/T

Supply Ability

50 Sets/month

High Precision 1.5KW Egg Yolk Weight Sorting Machine For Food Industry

Get Best Price

video

30Times/Min OD 350mm Weight Sorter Machine , Automated Sorting System

Get Best Price

video

High Speed 160Times/Min 1,000g Weight Sorting Machine For Seafood

Get Best Price

video

High Accuracy Australian Lobster Weight Sorting Machine 2 Level 6 Level Grading Machine

Get Best Price

Contact Now

Product Description

Horizontal Multi-Weight Sorting Conveyor Weighing For Raw Fish Lobster

Application:

This fruit sorting machine is mainly used for apple, pear, dragon fruit, orange, peach, kiwi fruit and guava, etc round shapes of fruit and vegetable sorting and grading. This machine is to sort the fruit by fruit weight.

Main features:

1. Collect data automatically with accuracy -Data are collected in one pass without operator's intervention, ensuring its accuracy

2. Exception alarm - The equipment will alarm when Packages' weight and dimention are beyond limit or the code can not be read

3. Highly flexible with expandability - The equipment can be equipped with cameras with different resolution - It can be connected to telescopic conveyor and conveyor belt

Technical Specification:

Model	TY-CW-YP
Power Supply	AC220V±10% 50HZ(60HZ)
Rated Power	0.6KW
Checking Range	≤500g
Accuracy	±0.3g~±3g
Minimum Scale	0.1g
Optimal Throughput	300 pcs/min
Suitable Product Dimension	≤120mm L*80mm W
Magazine size	173mm*91mm
Rejector	Drop
Control Module	High Speed A/D Sampling Module
Product Preset	99
Conveyor Direction	Rotary
Operating Requirement	Temperature: 0℃~40℃,Humidity:30%~95%
Machine Body Construction	SUS304 Full Stainless Steel

Customer-made Case:

500g Weight Sorting Machine 0

CE Certificate Weight Sorting Machine

300times/min conveyor belt sorting system

SUS304 Weight Sorting Machine
