Weighing PLC Touch Screen powder weighing Packaging Machine Manufacturer For powder
Standard Features
· Products dosing, Filling, Laminate heat sealable pouch making and sealing.
· Stainless steel 304 structure and surface
· Weighing and Packaging PLC & HMI Control Integrated, More stable operation, Easy for parameter setting
· Simple changing of pouch former, to adapt different pouch size requirement
· Intelligent temperature controlling configuration, ensure the artistic and neat sealing
· Configure with packaging film pre-pulling device, to enable stable pouch making
· No film no filling, and easy to change the packaging film
Specifications:
| Model |
TY-A-M14-1; TY-A-P14-1 |
| Max. Weighing (one hopper) |
5-200g |
| Accuracy |
x (0.5) |
| Min. Scale Interval |
0.1g |
| Max. Speed |
120 WPM |
| Hopper Volume |
0.8L/0.5L |
| Control System |
MCU / PLC |
| HMI |
7’’ / 10’’ color touch screen |
| Power Supply |
AC220V ±10% 50HZ / 60HZ, 2KW |
| Packing Dimension |
1,370(L)*1,060(W)*1,105(H)mm |
| Package weight |
240kg |
Applications:
· This machine is suitable for sticky & hygroscopic powders like fruit powder, flour, coffee, milk powder, spray dried detergent powder, custard powder, glucose powder, bean powder, spices, henna powder, protein powder, baking powder, water chestnut starch,and other powder in center seal pouches etc.
· Various bag types are available, e.g. pouch, back-sealing bag,linking bags,etc.
