Automatic Rotary Vacuum Filling and Packing machine Vacuum Feeding Packing machine Vacuum Weighing Packing Machine
To bag type automatic vacuum packaging machine can use the robot will vacuum packaging bag automatically take the bag, automatic prop open, automatic printing production date and batch number, automatic feeding, automatic vacuum packaging, realize the unmanned operation, truly realize the automation of packaging.
Machine Features
(1) Easy to operate, PLC control, with touch screen man-machine interface control system, easy to operate;
(2) Frequency conversion speed control, this machine uses frequency conversion speed control device, the speed can be adjusted at will within the prescribed range;
(3) automatic detection function, such as not open the bag or open the bag is incomplete, no refilling, no heat sealing, the bag can be reused, no waste of materials, for the user to save production costs;
(4) Safety device, when the working air pressure is not normal or the heating tube failure, it will be alarmed and prompted;
(5) Horizontal bag feeding mode, the bag storage device can store more bags, lower quality requirements for bag formation, high rate of bag separation and bag loading;
(6) Adjustment of bag width is controlled by motor, press and hold the control button to adjust the width of each group of machine clamps at the same time, easy to operate and save time;
(7) Adopting oil-free vacuum pump to avoid the pollution of production environment;
(8) The zipper bag opening mechanism is specially designed for the characteristics of zipper bag opening to avoid deformation or breakage of bag opening;
(9) In line with the hygiene standards of the food processing industry, the parts of the machine in contact with the materials or bags are processed with stainless steel or other materials in line with the food hygiene requirements to ensure food hygiene and safety.
Technical Parameters
Model |
TY-8S |
Bag Size |
flat bags, aluminum foil bags, composite flat bag |
Packaging Speed |
20-55 BPM |
Powder Supply |
3 phase 380V AC±10% 50Hz |
Use Power |
2.0kW/unit |
Air Consumption |
5-8kg f/cm³, Air consumption:0.4m³/min |
Operating Noise |
Within 80db (within 1m) |
Bag Opening Method |
Vacuum bag opening |
