14 Hoppers Multihead Weigher Packing Machine 0.8L 1.6L 2.5L for Fragile Fruits

14 Hoppers Multihead Weigher Packing Machine 0.8L 1.6L 2.5L for Fragile Fruits

2.5L Multihead Weigher Packing Machine

14 Hoppers Multihead Weigher Packing Machine

120P/M Multihead Weigher Packing Machine

Place of Origin:

Zhongshan, Guangdong China

Brand Name:

TOUPACK

Certification:

CE/ISO

Model Number:

TY-A-M/P14-1

Contact Us
Request A Quote
Product Details
Main Frame:
Stainless Steel
Voltage:
AC 220V ±10% 50HZ/60HZ, 1.5KW
Driven Type:
Electric
Application:
Factory, Workshop
After-sales Service Provided:
Technical Service
Condition:
New
Main Function:
Weighing Automatically
Machine Type:
14 Heads Multihead Scales, 0.8L 1.6L 2.5L
Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
Wooden Case
Delivery Time
15-30 Working Days
Payment Terms
L/C, T/T
Supply Ability
50 Sets/Month
Product Description
14 Hoppers Multihead Weigher Packing Machine 0.8L 1.6L 2.5L for Fragile Fruits
Product Specifications
Attribute Value
Main Frame Stainless Steel
Voltage AC 220V ±10% 50HZ/60HZ, 1.5KW
Driven type Electric
Application Factory, Workshop
After-sales service Technical Service
Condition New
Main Function Weighing Automatically
Machine type 14 heads Multihead Scales, 0.8L 1.6L 2.5L
Product Description
14 Weighing Hoppers Multihead Weighers Packaging Machine with 7''/10'' Touch Screen, 0.8L 1.6L 2.5L
Application

Suitable for various granular products and non-food items including:

  • Food products (candy, coffee beans, chocolate beans, frozen fruits)
  • Pharmaceutical items
  • Hardware components
  • Chemical and plastic materials
  • Small-sized/dosed products
Key Features
  • Expert digital weighing module with exceptional accuracy and stability
  • Choice of MCU or PLC control systems
  • Upgradable HMI program via USB with 16 language options
  • Factory parameters recovery function with 99 preset product parameters
  • Intelligent weighing hoppers discharge to prevent product blocking
  • Real-time monitoring of vibrator pans and weighing hoppers
  • Optional SUS304 or SUS316 main frame construction
  • IP65 dust and waterproof rating with water-cleaning capability
  • Modular control system design for cost-effectiveness and easy maintenance
Technical Specifications
Model TY-A-M/P14-1 TY-A-M/P14-2
Weighing Range 5-200g 20-1500g
Accuracy x(0.5) x(0.5)
Min. Scale Interval 0.1g 0.1g
Max. Speed 120 P/M 120 P/M
Hopper Volume 0.8L 1.6L/2.5L
Control System MCU/PLC MCU/PLC
HMI 7''/10'' Touch screen 7''/10'' Touch screen
Power Supply AC220V ±10% 50HZ/60HZ, 1.5KW AC220V ±10% 50HZ/60HZ, 1.5KW
Packing Dimension 1,370*1,060*1,105mm (L*W*H) 1140*1140*1853 (L*W*H)
Gross Weight 240KGS 500KGS
Compatible Supporting Equipment
  • HFFS and VFFS Packaging Machines
  • Multihead Weighers, Linear Weighers, Auger Fillers, Counting Machines
  • Horizontal Premade-Bag Filling Machines, Rotary Packing Machines
  • Secondary Packaging Machines for small-to-big bag conversion
  • Automatic Bag Feeding Packaging Machines
  • Check Weighers, Metal Detectors, X-Ray Inspection Systems
  • Various Elevator Types (Z-Type, Bowl-Type, Inclined)
Customization Information

To provide the optimal solution, we need to know:

  • Product type you need to weigh
  • Target weight requirements
  • Local voltage specifications
  • Required speed and accuracy levels
  • Existing equipment (packing machines, elevators, conveyors)

Our strength lies in providing complete customized integration systems including weighing, packaging, conveying, and detecting equipment - all from a single supplier for your convenience.
