10 Hoppers 0.5L 1.2L Linear Weigher machine For Tiny Mesh Material Like Salt Sugar

10 Hoppers 0.5L 1.2L Linear Weigher machine For Tiny Mesh Material Like Salt Sugar

1.2L Linear Weigher Machine

10 Hoppers Linear Weigher Machine

PLC Linear Weigher Machine

Place of Origin:

CHINA

Brand Name:

TOUPACK

Certification:

CE

Model Number:

TY-A-M/P10-1

Contact Us
Request A Quote
10 Hoppers 0.5L 1.2L Linear Weigher machine For Tiny Mesh Material Like Salt Sugar
Product Details
Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
USD 9000
Packaging Details
WOODEND CASES
Delivery Time
25 WORKING DAYS
Supply Ability
50 SETS PER MONTH
RELATED PRODUCTS
Good price Stainless Steel Industrial Use Multihead Weigher Combination Weighing Machine M14L1.6 online video

Stainless Steel Industrial Use Multihead Weigher Combination Weighing Machine M14L1.6

Get Best Price
Good price Popcorn packaging and weighting machine online

Popcorn packaging and weighting machine

Get Best Price
Good price 14 Head Multihead Weigher Pet Packing Machine Fish Puppy Dog Cat Food Weighing Plant 120g 240g 400g 1kg Ziplock Packing Machine online video

14 Head Multihead Weigher Pet Packing Machine Fish Puppy Dog Cat Food Weighing Plant 120g 240g 400g 1kg Ziplock Packing Machine

Get Best Price
Good price Wet Pet Food And Dry Pet Food Multihead Weigher Packing Machine Dog Cat Food Weighing 120g 240g 400g 1kg Pouch Packing Machine online video

Wet Pet Food And Dry Pet Food Multihead Weigher Packing Machine Dog Cat Food Weighing 120g 240g 400g 1kg Pouch Packing Machine

Get Best Price
Contact Us
Contact Now
Product Description

10 Weighing Hoppers Multihead Weighers Packaging Machine with 7''/10'' Touch Screen



Application:



With wide-range of application, for weighing granular, bar-shaped products, such as sunflower / melon seeds, puffed food, almonds, pistachios, nuts, candies, beans, frozen food, dry fruits, pet food, snacks, hardware and chemicals.





Main Parameters:



1. Professional digital weighing module with high precision and good stability
2. Control system: MCU or PLC (optional).
3. HMI program with different levels of authorized access, up to 16 different languages for choice, be upgraded through USB
4. Factory parameters recovery function, 99 preset product parameters to meet different parameter program requirements
5. Weighing hopper able to discharge in turn to effectively prevent products from blocking
6. Weighing and counting function to meet diverse needs from customers
7. Real-time display to better monitor the running status of the vibrator pan and the weighing hoppers
8. Machine main frame can be SUS304/316 (optional)
9. Being able to make the hoppers open for cleaning with IP65 dust and waterproof
10. Modular design of control system make the weigher cost-effective and easy to be maintained



Special Features:



Model TY-A-M/P10-1 TY-A-M/P10-2
Weighing Range 5-200g 20-1000g
Accuracy x(0.5) x(0.5)
Min.Scale Interval 0.1g 0.1g
Max. Speed 60 P/M 60 P/M
Hopper Volume 0.8L 1.6L/2.5L
Control System MCU/PLC MCU/PLC
HMI 7''/10'' Touch screen 7''/10'' Touch screen
Power Supply AC220V ±10% 50HZ/60HZ, 1.5KW AC220V ±10% 50HZ/60HZ, 1.5KW
Packing Dimension 1,370*1,060*1,105mm (L*W*H) 1140*1140*1853 (L*W*H)
Gross Weight 220KGS 385KGS



Relevant Supporting Machine:



1. HFFS Packaging Machine, VFFS Packaging Machine
2. Multihead Weigher, Linear Weigher, Auger Filler, Counting Machine
3. Horizontal Premade-Bag Filling Machine, Rotary Packing Machine
4. Small Bag into Big Bag Secondary Packaging Machine
5. Automatic Bag Feeding Packaging Machine
6. Check Weigher, Metal Detector, X-Ray Inspection System
7. Z-Type Elevator, Bowl-Type Elevator, Inclined Elevator





It Is Important for Us to Learn More About Your Products And Requirements:



1. What kind of product do you want to weigh?
2. What is the target weight?
3. What is the voltage locally?
4. What is the required speed and accuracy?
5. Do you have a packing machine, elevator or conveyor?



Our Strength:



We are capable of providing our customers with customized integration systems, including weighing, packaging, conveying, and detecting equipment. And it is very convenient for you to buy a system from one company, too.
