Frozen Fruits Mixing And Weighing System 20 Head 24 Head 32 Head Weigher Freeze-Dried Vegetables Packing Machinene
Solution Units
① 20 head/24 head/32 head weigher:304 stainless steel main structure, dimple plate is more suitable for viscous materials; Anti-condensation device to protect circuit, can be used in sub-zero working environment; Equipped with timing hopper; Standard ring skirt retaining device to prevent material sliding.
② Inclined elevator:304 stainless steel main structure, with 200L silo, at the same time each elevator is equipped with (dimple plate) independent vibration feeder, The top of the four elevators is connected with the guiding chute extending to the four sections of the upper hopper.
③ Independent vibrating feeder. 304 stainless steel main structure, dimple plate, can reduce the material adhesion, is conducive to uniform feeding.
④ Supporting platform:304 stainless steel main structure, stainless steel anti-slip pavement plate.
⑤ Bowl-type elevator:Limited by the height of the plant, this system requires bowi-type elevator for secondary lifting; 304 stainless steel main structure; Spray teflon inside the bowl to reduce material stickiness
⑥ Finished product conveyor:304 stainless steel main structure, used to transport finished products.
System Parameters
| System name | Frozen fruits mixing and weighing system |
| Weighing products | Strawberries, blueberries, blackberries. chopped pineapple/apple |
| Target weight | 283.5g/10oz, 341g/12oz, 567g/20oz |
| Total target weight accuracy | 0.5%-1% |
| System speed | 30 bags/min |
| Voltage | 220VAC, 50/60Hz |
