Place of Origin:
China
Brand Name:
TOUPACK
Certification:
CE
Model Number:
X Ray Metal Detector
TOUPACK X-Ray Inspection Systems use advanced X-ray imaging technology to inspect packaged products, bulk materials, and solid test objects for internal foreign objects and defects. Unlike conventional visual inspection, X-ray technology can identify contaminants hidden inside products or packaging, helping improve product safety and quality control.
From foreign object detection to production-line quality control, TOUPACK X-Ray Inspection Systems help manufacturers achieve safer products, more reliable inspection and higher production efficiency.
The use of X-ray imaging technology enables inspection of packaged products, bulk products, and solid test objects for internal defects and foreign objects. Among the types of foreign objects detected include: metal, bone, glass, ceramics, stone, PVC, rubber, and more.
| Model Number | TTX-2417K100 | TTX-4017K100 | TTX-5026K100 | TTX-6035K100 |
|---|---|---|---|---|
| X-ray Source | 40-100kv adjustable | 40-100kv adjustable | 40-120kv adjustable | 210W/480/40-100kv adjustable |
| Detection Width | 240mm | 400mm | 500mm | 600mm |
| Detection Accuracy | SUS304 ball (ф) 0.3mm | SUS304 ball (ф) 0.4mm | SUS304 wire 0.2x2mm | SUS304 wire 0.2x2mm |
| Glass Ball (ф) | 1.0mm | 1.0mm | - | - |
| Ceramic Ball (ф) | 1.0mm | 1.0mm | - | - |
| Conveyor Speed | 0-70m/min | 0-70m/min | 0-70m/min | 0-70m/min |
| Size Height | 170mm | 170mm | 260mm | 350mm |
