Name: 150W Metal Detector X Ray Machine
Brand: GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD
SKU: TYA-MD3011
Price: 18,500.00 USD
Availability: InStock

Home > Products > X Ray Metal Detector >

150W Metal Detector X Ray Machine

170mm height metal detector x ray machine

150W metal detector x ray machine

150W conveyor type needle detector

Place of Origin:

Guangdong Zhongshan China

Brand Name:

TOUPACK

Certification:

CE ISO9001

Model Number:

TYA-MD3011

Request A Quote

Product Details

X-ray Light Source::

150W/100KV

Detecting Width::

240mm

Detecting Height::

170mm

Accuracy:

SUS Ball Φ0.3mm, SUS Wire Φ0.2*2mm

Transfer Speed:

10-70m/ Min

HMI:

17 Inch Colorful Touch Screen

X-ray Leakage:

1 Millisievert / Hour

System:

Windows 7

Power Supply:

AC220V±10% 50Hz(60Hz) 1.5kVA Max

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiable

Packaging Details

wooden case

Delivery Time

10-25 working days

Payment Terms

L/C, D/P, T/T

Supply Ability

30set per month

SUS 304 X Ray Detecting Machine For Metal Or Non Metal Foreign Material Contamination

Get Best Price

video

150W Metal Detector X Ray Machine

Get Best Price

High Stability SUS304 300mm Width X Ray Metal Detector In Food Industry

Get Best Price

TOUPACK 3Ton/H X Ray Metal Detector Waterproof For Powdered Products

Get Best Price

Contact Now

Product Description

150W Metal Detector X Ray Machine

Product Specifications

Attribute	Value
X-ray Light Source	150W/100KV
Detecting Width	240mm
Detecting Height	170mm
Accuracy	SUS ball Φ0.3mm, SUS wire Φ0.2*2mm
Transfer speed	10-70m/min
HMI	17 inch colorful touch screen
X-ray Leakage	1 millisievert/hour
System	Windows 7
Power supply	AC220V±10% 50Hz(60Hz) 1.5kVA Max

Product Description

High Accuracy X-Ray Horizontal Automated Optical Toy Food X Ray Inspection Systems

Application

Used for detecting metallic and non-metallic material and defects in food, chemical, pharmaceutical industry, such as glass, ceramics, stones, bones, hard rubber and plastic.

Main Features

Health design, Easy disassembly: The frame adopts the structure of complete welding. Detection head is not easy to accumulate dust and meet HACCP requirements. The contact parts are made of food grade materials to minimize product contamination. The frame can be quickly disassembled, cleaned and reassembled.
Efficient operation: Multilingual operating system only need least training to quickly automatic setting and change product and also have automatic search program to shorten shutdown time.
Digital signal processing + Super memory: Using the most advanced digital signal processing and dual channel technology. Meanwhile, memory is also increased to maximum storage of 99 kinds of products. Different products can be set to different sensitivity so as to save costs.

Configuration

Frequency converter: Danfoss (Denmark)
X ray collector: Detection Technology(DT) (Finland)
Industrial air conditioning: Pfannenberg (Germany)
X ray: VJ GROUP (USA)
PLC: MITSUBISHI (Japan)
Limit switch: OMRON (Japan)

Detailed Specifications

Model	TTX-2417K100	TTX-4017K100	TTX-5026K100	TTX-6035K100
X-ray Light Source	150W/100KV	210W/100KV	350W/100KV
Detecting Width	240mm	400mm	500mm	600mm
Detecting Height	170mm	170mm	260mm	350mm
Accuracy	SUS ball Φ0.3mm, SUS wire Φ0.2*2mm
Transfer speed	10-70m/min
HMI	Germany 17 inch touch screen
Connectivity	LAN Port, USB Port
Working environment	Working temperature: -10℃~40℃ (Cooling method: Air conditioned cooling), Working humidity: 30%~90%, No dewing (Humidity controlling: Anti-humidity device)
X-ray Leakage	1 millisievert/hour
Protection method	Lead-free protective curtain (easy for disassembling)
Alarming method	Acousto-optic alarming
Power Supply	AC220V ± 10% 50Hz(60Hz) 1.5kVA Max
Body Material	SUS304
