Home > products > X Ray Metal Detector >
High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner

High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner

X-ray Food Safety Metal Detector

High Sensitivity Food Safety Metal Detector

Place of Origin:

China

Brand Name:

TOUPACK

Certification:

CE

Model Number:

X Ray Metal Detector

Contact Us
Request A Quote
High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner
Product Details
X-ray Light Source:
40-100kV
Conveyer Speed:
10-70m/min
HMI:
17 Inch German LMl Industrial Touch Screen
X-ray Leakage:
<1uSv/hour
Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Wooden box packaging
Delivery Time
30 days
Payment Terms
L/C, T/T
RELATED PRODUCTS
Good price High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner online

High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner

Get Best Price
Good price X Ray Metal Detector For Metal Can Products With Rejectors X-Ray Scanner online video

X Ray Metal Detector For Metal Can Products With Rejectors X-Ray Scanner

Get Best Price
Good price ISO9001 600mm Belt X Ray Metal Detector , X Ray Inspection Machine online video

ISO9001 600mm Belt X Ray Metal Detector , X Ray Inspection Machine

Get Best Price
Good price TTX-2417K100 X-Ray Detecting System Etallic Food Inspection online video

TTX-2417K100 X-Ray Detecting System Etallic Food Inspection

Get Best Price
Contact Us
Contact Now
Product Description

High Sensitivity Food Safety Metal Detector X-ray Food Scanner for Metal Can Products with Rejectors X-ray Scanner



The X-ray inspection system inspects, detects, and automatically rejects hazardous foreign objects from your production line. At
the same time, the system is able to inspect the overall quality by analyzing the content of the packaged product, such as:
* Completeness and integrity
* Form and shape
* Presence and lack of presence
* Fill level

These features of X-ray inspection systems are a huge benefit for food producers, who want to reach the highest level of product
safety and quality. With the added traceability that X-ray inspection systems offer, food companies are also able to prove that
their products were indeed safe and high quality when leaving the production facilities.



High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 0High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 1High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 2High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 3

The use of X-ray imaging technology, can bepackagedproducts,bulk products, solid test objects for internal and defects onthedetection. Among the types of foreign objects to be detected include:metal, bone, glass, ceramics, stone, PVC, rubber, and so on.





Technical parameters
model number TTX-
2417K100		 TTX-
4017K100		 TTX-
5026K100		 TTX-
6035K100
X-ray source 40-100kv adjustable 40-100kv adjustable 40-120kv adjustable 210W/480/40-100kv adjustable
Detection width 240mm 400mm 500mm 600mm
Detection accuracy SUS304 ball (ф) 0.3mm 0.4mm
SUS304 wire 0.2x2mm 0.2x2mm
Glass ball (ф) 1.0mm 1.0mm
Ceramic ball (ф) 1.0mm 1.0mm
Conveyor speed 0-70m/min 0-70m/min 0-70m/min 0-70m/min
Size Height 170mm 170mm 260mm 350mm



High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 4High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 5High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 6High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 7High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 8High Sensitivity Food Safety Metal Detector For Metal Can Products With Rejectors X-ray Food Scanner 9

Tags：

SUS304 X Ray Metal Detector

5ton/h X Ray Metal Detector

300mm width X Ray Metal Detector
